| Machineno | 2070-E23050 |
| Machine type | Gear Testing Machine |
| Make | HOEFLER |
| Type | EMZ 631 |
| Build year | |
| Control | CNC |
| Storage location | Malsch stock |
| Origin | Germany |
| Delivery time | immediately |
| Freight basis | immediately |
| Price | on request |
| max. wheel diameter | 5 - 630 mm |
| gear width | 500 mm |
| max. module | 20 |
| min. module | 0,5 |
| workpiece weight | 350 kg |
| Control | IBH Macro |
| max. workpiece diameter | 630 mm |
| clamping length | 1050 mm |
| total power requirement | 1,8 kW |
| weight of the machine ca. | 2,5 t |
| dimensions of the machine ca. | 2,0 x 0,7 x 2,4 m |
|
Spur gear software for internal and external gearing Profile inspection standard crowning head - root relief K - profile Direction test standard crowning head - root relief K - profile graduation test Axis position correction for on-the-fly measurements up to 0.2 mm axis position error Snail software 3 carriers for gears, 1 carrier block, calibration device |
