| Machineno | 2070-E22074 |
| Machine type | Tool Room Milling Machine - Universal |
| Make | DECKEL |
| Type | FP 2 NC / DIALOG 11 |
| Build year | 1984 |
| Control | CNC |
| Storage location | Malsch stock |
| Origin | Deutschland |
| Delivery time | immediately |
| Freight basis | immediately |
| Price | on request |
| x-travel | 300 mm |
| y-travel | 300 mm |
| z-travel | 400 mm |
| CNC-control | DIALOG 11 |
| spindle taper ISO | 40 |
| spindle turning speed range | 31 - 5.000 U/min |
| table-size | 620 x 390 mm |
| table load | 250 kg |
| power capacity | 5,5 kW |
| feeds -stepless- | 2 - 6.000 mm/min |
| quill stroke | 80 mm |
| coolant | |
| voltage | 380 V |
| total power requirement | 11,0 kVA |
| weight of the machine ca. | 1,65 t |
| dimensions of the machine ca. | 1,85 x 1,90 x 1,80 m |
| electric cabinet | 1,35 x 0,70 x 1,70 m |
| coolant tank | 1,00 x 0,45 x 0,20 m |
|
Machine from training workshop! ° Engine brake ° Safety handwheels ° 2 x emergency stop switches Accesories: * Rigid angle table * Coolant facility |
